Hydrogen Generator
Hydrogen Generator DTH500
| Features and Advantages |
| 1-SPE solid electrolyte technology; |
| 2-Effective protection of GC column by direct electrolysis of pure water without alkali; |
| 3-Adopt imported high quality ionic membrane |
| 4-Silicone rubber ring (low sulfur content) is used inside the instrument to effectively improve gas quality and ensure the chromatographic baseline is stable, suitable for NPD and FPD; |
| 5-Integrated pressure and flow control; |
| 6-Automatic water level control, when the state of water shortage, automatic shutdown, effective protection of the electrolytic cell, extend the service life; |
| 7-It can be used for any type of gas chromatograph produced by any manufacturer around the world. |
| 8- No maintenance |
Technical Parameter
Hydrogen
Purity
99.999%
Output Flow
0-500ml/min
Output Pressure
0-0.4Mpa
Pressure Fluctuation
< 0.001MPa
Power Supply
220V±10%,
50Hz 110V±10%
Power Consumption
250W
Dimension
400*360*220mm
Net Weight
14kg
Service
We provide after sales support by the way of
1 on line service
2 video service
Strong technical team is ready to respond and help you to resolve any problem encountered by you .
Application ： Lab ，Pharmacy , Petroleum
Certificate : CE ISO
