ULT Freezer-DMDF-86V588E
Product Description
ULT Freezer-DMDF-86V588E
Overview
Application
To transport and transfer blood, plasma, vaccine, reagents and special medicines in medical and logistics industry.
Features
Multiple voltage used as AC220V or DC12V/24V, power supply of cigarette lighter
Whole roll PE structure
Combined with forced air cooling system and direct cooling system
Multi-function: 3 ranges of inner temperature: 2℃ ~8 ℃ used as pharmacy refrigerator
-10℃~ - 25 ℃ used as deep freezer
22 ± 2℃ used as incubator
Security Guarantee
Functional alarm system with audible and visible
The whole roll structure prevents collision damage.
Multilayer stacking
| Model | MDF-86V588E | |
| Specificaitons | Shelf/drawer QTY | Stainless steel shelf/3 |
| Cooling | Direct cooling | |
| Defrost | Manual | |
| Refrigerant | Mixed-gas | |
| Power Consumption(kWh/24h) | 16.5 | |
| Noise（db) | 53 | |
| Ambient temperature（℃） | 10~32℃ | |
| Temperature range（℃） | -40~-86℃ | |
| Cooling system | Compressor brand/QTY | SECOP/2 |
| Sensor | PTC | |
| Temperature controller | Microprocessor | |
| Display | Digital display | |
| Power | Voltage/frequency（V/Hz) | 220/50Hz |
| Power（W) | 1500W | |
| Current（A) | 9.1A | |
| Material | Inside material | Stainless steel |
| Outside material | Color sprayed steel | |
| Insulation | PURF | |
| Size | Capacity（L/cu.ft) | 588/20.76 |
| NT./GT.（kg) | 290/360 | |
| Exterior size(W*D*H)(mm) | 880*1090*1995 | |
| Interior size(W*D*H)(mm) | 606*738*1310 | |
| Package size(W*D*H)(mm) | 970*1140*2190 | |
| CBM | 2.42 | |
| 20GP/40GP/40HQ | 12/24/24 | |
| Frozen Racks | Racks | 16(5X5) |
| Boxes (2 Inches) | 400 | |
| Samples(2ml) | 40000 | |
| Alarm | High/low temperature | Y |
| Power failure | Y | |
| Abnormal voltage | Y | |
| Sensor error | Y | |
| Filter screen check | Y | |
| Thermostat failure | Y | |
| Low battery | Y | |
| Condenser clean | Y | |
| High ambient temperature | Y | |
| Door ajar | Y | |
| Optional | Castor | Y |
| Inside door | 2 | |
| Test hole QTY/diameter | 1/25MM | |
| USB port | Y | |
| Chart recorder | / | |
| Data logger | / | |
| Power failure backup system(alarm) | 72h | |
| Remote alarm port | Y | |
| CO2 back up system | Optional | |
| LN2 back up system | Optional | |
| Other | Certification | ISO.CE |
